www.ti.com
Functional Description
Table 26-1. ROM Exception Vectors
Address Exception Content
20000h Reset Branch to the Public ROM Code startup
20004h Undefined PC = 4030CE04h
20008h SWI PC = 4030CE08h
2000Ch Pre-fetch abort PC = 4030CE0Ch
20010h Data abort PC = 4030CE10h
20014h Unused PC = 4030CE14h
20018h IRQ PC = 4030CE18h
2001Ch FIQ PC = 4030CE1Ch
Public ROM Code CRC
The Public ROM Code CRC is calculated as 32 bit CRC code (CRC-32-IEEE 802.3) for the address range
20000h–2BFFFh. The four bytes CRC code is stored at location 20020h.
Dead Loops
Built-in dead loops are used for different purposes as shown in below Table 26-2. All dead loops are
branch instructions coded in ARM mode. The fixed location of these dead loops facilitates debugging and
testing. The first seven dead loops are default exception handlers linked with RAM exception vectors. The
dead loops might be called directly from the user code. However there exists a special function which can
be called from ROM Code in order to execute a dead loop. The function is an assembly code in ARM
mode which takes the dead loop address from R0 register. The main purpose of the function is to go in a
dead loop until the watchdog expires and resets the device. The function is located at address 200C0h. In
addition the function clears global cold reset status upon issuing the global SW reset.
Table 26-2. Dead Loops
Address Purpose
20080h Undefined exception default handler
20084h SWI exception default handler
20088h Pre-fetch abort exception default handler
2008Ch Data abort exception default handler
20090h Unused exception default handler
20094h IRQ exception default handler
20098h FIQ exception default handler
2009Ch Validation tests PASS
200A0h Validation tests FAIL
200A4h Reserved
200A8h Image not executed or returned.
200ACh Reserved
200B0h Reserved
200B4h Reserved
200B8h Reserved
200BCh Reserved
Code
This space is used to hold code and constant data.
Public ROM Code Version
The ROM Code version consists of two decimal numbers: major and minor. It can be used to identify the
ROM Code release version in a given IC (e.g., useful to identify an IC version). The ROM Code version is
a 32bits hexadecimal value located at address 2BFFCh.
4099
SPRUH73H–October 2011–Revised April 2013 Initialization
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
