Texas Instruments AM335 Series Technical Reference Manual

EDMA3 Registers www.ti.com
Table 11-25. EDMACC Registers (continued)
Offset Acronym Register Description Section
0368h DRAE5 DMA Region Access Enable Register for Region 5 Section 11.4.1.3.1
036Ch DRAEH5 DMA Region Access Enable Register High for Region 5 Section 11.4.1.3.1
0370h DRAE6 DMA Region Access Enable Register for Region 6 Section 11.4.1.3.1
0374h DRAEH6 DMA Region Access Enable Register High for Region 6 Section 11.4.1.3.1
0378h DRAE7 DMA Region Access Enable Register for Region 7 Section 11.4.1.3.1
037Ch DRAEH7 DMA Region Access Enable Register High for Region 7 Section 11.4.1.3.1
0380h-039Ch QRAE0-7 QDMA Region Access Enable Registers for Region 0-7 Section 11.4.1.3.2
0400h-04FCh Q0E0-Q3E15 Event Queue Entry Registers Q0E0-Q3E15 Section 11.4.1.4.1
0600h-060Ch QSTAT0-3 Queue Status Registers 0-3 Section 11.4.1.4.2
0620h QWMTHRA Queue Watermark Threshold A Register Section 11.4.1.4.3
0640h CCSTAT EDMA3CC Status Register Section 11.4.1.4.4
0800h MPFAR Memory Protection Fault Address Register Section 11.4.1.5.1
0804h MPFSR Memory Protection Fault Status Register Section 11.4.1.5.2
0808h MPFCR Memory Protection Fault Command Register Section 11.4.1.5.3
080Ch MPPAG Memory Protection Page Attribute Register Global Section 11.4.1.5.4
0810h-082Ch MPPA0-7 Memory Protection Page Attribute Registers 0-7 Section 11.4.1.5.4
1000h ER Event Register Section 11.4.1.6.1
1004h ERH Event Register High Section 11.4.1.6.1
1008h ECR Event Clear Register Section 11.4.1.6.2
100Ch ECRH Event Clear Register High Section 11.4.1.6.2
1010h ESR Event Set Register Section 11.4.1.6.3
1014h ESRH Event Set Register High Section 11.4.1.6.3
1018h CER Chained Event Register Section 11.4.1.6.4
101Ch CERH Chained Event Register High Section 11.4.1.6.4
1020h EER Event Enable Register Section 11.4.1.6.5
1024h EERH Event Enable Register High Section 11.4.1.6.5
1028h EECR Event Enable Clear Register Section 11.4.1.6.6
102Ch EECRH Event Enable Clear Register High Section 11.4.1.6.6
1030h EESR Event Enable Set Register Section 11.4.1.6.7
1034h EESRH Event Enable Set Register High Section 11.4.1.6.7
1038h SER Secondary Event Register Section 11.4.1.6.8
103Ch SERH Secondary Event Register High Section 11.4.1.6.8
1040h SECR Secondary Event Clear Register Section 11.4.1.6.9
1044h SECRH Secondary Event Clear Register High Section 11.4.1.6.9
1050h IER Interrupt Enable Register Section 11.4.1.7.1
1054h IERH Interrupt Enable Register High Section 11.4.1.7.1
1058h IECR Interrupt Enable Clear Register Section 11.4.1.7.2
105Ch IECRH Interrupt Enable Clear Register High Section 11.4.1.7.2
1060h IESR Interrupt Enable Set Register Section 11.4.1.7.3
1064h IESRH Interrupt Enable Set Register High Section 11.4.1.7.3
1068h IPR Interrupt Pending Register Section 11.4.1.7.4
106Ch IPRH Interrupt Pending Register High Section 11.4.1.7.4
1070h ICR Interrupt Clear Register Section 11.4.1.7.5
1074h ICRH Interrupt Clear Register High Section 11.4.1.7.5
1078h IEVAL Interrupt Evaluate Register Section 11.4.1.7.6
1080h QER QDMA Event Register Section 11.4.1.8.1
1084h QEER QDMA Event Enable Register Section 11.4.1.8.2
940
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
