TX Mode
Write
MaxP Bytes
to FIFO
£
Last Packet
No
Set TxPktRdy
Yes
Set TxPktRdy
and Set DataEnd
State IDLE®
Return
Functional Description
www.ti.com
16.3.8.1.1.4.3 TX Mode: Control Transfer of Peripheral Mode
When the endpoint is in TX state, all arriving IN tokens need to be treated as part of a data phase until the
required amount of data has been sent to the host. If either a SETUP or an OUT token is received while
the endpoint is in the TX state, this will cause a SETUPEND condition to occur as the core expects only
IN tokens.
Three events can cause TX mode to be terminated before the expected amount of data has been sent as
shown in Figure 16-6:
1. The host sends an invalid token causing a SETUPEND condition (bit 4 of PERI_CSR0 is set).
2. The firmware sends a packet containing less than the maximum packet size for Endpoint 0.
3. The firmware sends an empty data packet.
Until the transaction is terminated, the firmware simply needs to load the FIFO when it receives an
interrupt which indicates that a packet has been sent from the FIFO. An interrupt is generated when
TXPKTRDY is cleared.
When the firmware forces the termination of a transfer (by sending a short or empty data packet), it should
set the DATAEND bit of PERI_CSR0 (bit 3) to indicate to the core that the data phase is complete and
that the core should next receive an acknowledge packet.
Figure 16-6. Flow Chart of Transmit Data Stage of a Control Transfer in Peripheral Mode
