Functional Description
Table 26-14. Supported NAND Devices (continued)
Capacity Device ID Bus Width Page size
2 Gb 83 x8 2048
2 Gb 93 x16 2048
4 Gb DC x8 2048
4 Gb CC x16 2048
4 Gb AC x8 2048/4096
4 Gb BC x16 2048/4096
4 Gb 84 x8 2048
4 Gb 94 x16 2048
8 Gb D3 x8 2048/4096
8 Gb C3 x16 2048/4096
8 Gb A3 x8 2048/4096
8 Gb B3 x16 2048/4096
8 Gb 85 x8 2048
8 Gb 95 x16 2048
16 Gb D5 x8 2048/4096
16 Gb C5 x16 2048/4096
16 Gb A5 x8 2048/4096
16 Gb B5 x16 2048/4096
16 Gb 86 x8 2048
16 Gb 96 x16 2048
32 Gb D7 x8 2048/4096
32 Gb C7 x16 2048/4096
32 Gb A7 x8 2048/4096
32 Gb B7 x16 2048/4096
32 Gb 87 x8 2048
32 Gb 97 x16 2048
64 Gb DE x8 2048/4096
64 Gb CE x16 2048/4096
64 Gb AE x8 2048/4096
64 Gb BE x16 2048/4096
When the parameters are retrieved from the ROM table: page size and block size is updated based on 4
th
byte of NAND ID data. Due to inconsistency amongst different manufacturers, only devices which has
been recognized to be at least 2Gb (included) have these parameters updated. Therefore, the ROM Code
supports 4kB page devices but only if their size, according to the table, is at least 2Gb. Devices which are
smaller than 2Gb have the block size parameter fixed to 128kB. Table 26-15 shows the 4
th
ID Data byte
encoding used in ROM Code.
4121
SPRUH73H–October 2011–Revised April 2013 Initialization
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
